| Item项目 | Content 详细内容 |
Criterion 标准 |
Remarks 备注 |
| Over charge protect过充保护 | Protect delay time 保护延迟时间 |
500ms—1500ms | |
| Over charge release voltage(Cell) 单体过充解除电压 |
4.150V±0.050V | ||
| Over discharge protect过放保护 | Over discharge detection voltage(Cell) 单体过放保护电压 |
2.700V±0.080V | |
| Protect delay time 保护延迟时间 |
50ms—150ms | ||
| Over discharge release voltage(Cell) 单体过放解除电压 |
3.000V±0.100V | ||
| Over Current protect过流保护 | Overcurrent Discharge 放电过流保护 |
15A-25A | |
| Protect delay time 保护延迟时间 |
5ms—15ms | ||
| Protect relieve condition 保护解除条件 |
Cut load断开负载 | ||
| Overcurrent charge 充电过流保护 |
- | ||
| Protect delay time 保护延迟时间 |
- | ||
| Short Protection短路保护 | Detection delay time 检测延迟时间 |
100-600us | |
| Recovery condition 短路保护恢复条件 |
Cut short circuit . 断开负载.断开短路 |
||
| Dimension(L*W*T)尺寸 | 50*16*1.0mm | ||
