| NO序号 | Items项目 | 保护条件 | 保护延时时间 Delay time | 恢复条件 Release condition | ||
| Protection condition | ||||||
| 1 | Cell Over charge voltage Cell 过压保护 | 1级保护 1st level safty | 4.250V±0.025V | 2.0s±0.5s | 4.150±0.050V | |
| 2级保护 2nd level safty | - | - | - | |||
| 2 | Cell Under discharge voltage Cell欠压保护 | 1级保护 1st level safty | 2.500V±0.025V | 2.0s±0.5s | 3.000±0.050V | |
| 3 | Over current 过流保护 |
OCC1 Threshold | 7A±0.2A | 4.0s±0.5s | -200mA/5s | |
| OCC2 Threshold | 8A±0.2A | 2.0s±0.5s | -200mA/5s | |||
| OCD1 Threshold | 5.5A±0.2A | 2.0s±0.5s | 200mA/10s | |||
| OCD2 Threshold | 7A±0.2A | 1.0s±0.5s | 200mA/10s | |||
| AOLD Threshold | 50A±5.0A | 20ms-50ms | 0mA/5s | |||
| ASCC Threshold | 55A±5.0A | 350uS-600us | 0mA/5s | |||
| ASCD1 Threshold | 55A±5.0A | 600uS-1200us | 0mA/5s | |||
| ASCD2 Threshold | 66A±5.0A | 350uS-600us | 0mA/5s | |||
| 4 | Over temperature 温度保护 |
OTC Threshold | 65±3℃ | 5.0s±0.5s | 60±3℃ | |
| OTD Threshold | 70±3℃ | 5.0s±0.5s | 65±3℃ | |||
| OTF Threshold | 100±3℃ | 2.0s±0.5s | 80±3℃ | |||
| UTC Threshold | -20±3℃ | 2.0s±0.5s | -10±3℃ | |||
| UTD Threshold | -25±3℃ | 2.0s±0.5s | -20±3℃ | |||
| 5 | Charge 充电 |
input Charge current 输入充电电流 |
5.0A | |||
| input Charge Voltage 输入充电电压 |
19.0-24.0V | |||||
| output Charge current 输出充电电流 |
2.0A±0.2A | |||||
| output Charge Voltage 输出充电电压 |
16.8V±0.1V | |||||
| discharging current 放电电流 |
5.0A | |||||
| 6 | DC 12V | DC currentDC输出电流 | MAX:2.0A | |||
| DC VoltageDC输出电压 | 12.0V±0.3V | |||||
| 7 | (L*W*H)尺寸 | 120*36*1.0mm` | ||||
